DC-DC MINI560 Step-Down Voltage Regulator 3.3V 5V 9V 12V

DC-DC MINI560 High-Efficiency Step-Down Voltage Regulator Module

The DC-DC MINI560 is a compact, high-efficiency step-down (buck) voltage supply module designed for electronics hobbyists, engineers, and DIY builders. With selectable output voltages of 3.3V, 5V, 9V, and 12V, this mini module makes it easy to power a wide range of circuits and devices from a single input source — all in a tiny, space-saving form factor.

Whether you're building a custom power supply for a microcontroller, powering sensors, or integrating into a larger electronics project, the MINI560 delivers stable, regulated output with synchronous rectification for maximum efficiency and minimal heat generation.

Made in Mainland China.

Key Specifications

• Output Voltage: 3.3V / 5V / 9V / 12V (selectable)
• Input Voltage: 5.5V – 20V (minimum 2V differential required)
• Output Current: Up to 5A (peak) / 4A continuous; sustained loads above 4A/3A require additional heat dissipation
• Switching Frequency: 500 kHz
• Module Type: Non-isolated step-down (buck) converter
• Rectification Method: Synchronous rectification for high efficiency
• Material: Plastic + Metal
• Package Contents: 1 × MINI560 Voltage Regulator Module

Why Choose the MINI560?

• ✅ High Efficiency: Synchronous rectification minimizes energy loss and heat output
• ✅ Multi-Voltage Output: Four common voltage options in one compact module
• ✅ Wide Input Range: Compatible with a variety of DC input sources (5.5V–20V)
• ✅ Compact Design: Mini footprint fits easily into tight enclosures and PCB layouts
• ✅ Stable Output: Regulated voltage keeps your components protected and running smoothly

Perfect For

• Arduino, Raspberry Pi, and microcontroller power supplies
• DIY electronics and custom PCB projects
• Sensor modules, LED drivers, and small motor controllers
• Robotics, drones, and RC electronics
• Lab bench power conversion and prototyping

Important Notes

• For sustained output above 4A (or 3A depending on variant), ensure adequate heat dissipation is provided to maintain performance and longevity.
• Maintain a minimum 2V differential between input and output voltage for stable regulation.
• Actual color may vary slightly from product images due to monitor settings and lighting conditions.
• Please allow minor measurement tolerances for listed dimensions and specifications.
