DIP SMD Double Spring PCB Pogo Pin Connectors 20/50/100 Pcs

DIP & SMD Double Spring PCB Pogo Pin Connectors

Get reliable, low-resistance spring-loaded contact every time with these Double Spring Pogo Pin Connectors. Whether you're prototyping a new PCB design, building a battery contact assembly, or setting up a test fixture, these precision-machined contact needles deliver consistent electrical connectivity across hundreds of thousands of cycles. Available in convenient pack sizes of 20, 50, or 100 pieces, they suit hobbyists, engineers, and production teams alike.

Key Features

• Double Spring Design: Dual-spring mechanism ensures stable, self-compensating contact pressure for dependable connections even on uneven surfaces.
• DIP & SMD Compatible: Suitable for both through-hole (DIP) and surface-mount (SMD) PCB applications.
• Height Range 2–12 mm: Multiple height options to match your board layout requirements precisely.
• Spring-Loaded Contact: Spring-loaded needle tip self-adjusts to surface variations, maintaining solid electrical contact throughout testing and operation.
• Battery & Test Probe Use: Ideal for battery contact points, programming jigs, bed-of-nails fixtures, and general PCB test probes.
• CE & RoHS Certified: Meets CE and RoHS compliance standards — low voltage rated (below 50 V AC or 75 V DC), with no high-concern chemicals.
• Bulk Packs Available: Choose from 20, 50, or 100-piece sets to match your project scale and budget.

Specifications

• Type: Double Spring DIP / SMD Pogo Pin Connector
• Height: 2 mm – 12 mm
• Mounting: DIP (through-hole) & SMD (surface mount)
• Certification: CE, RoHS
• Voltage Rating: Low voltage — below 50 V AC / 75 V DC
• Quantity Options: 20 pcs / 50 pcs / 100 pcs
• Country of Origin: Made in Mainland China

Common Applications

• PCB test fixtures and bed-of-nails testers
• Battery contact assemblies and charging docks
• Firmware programming jigs
• Prototyping and R&D lab setups
• Wearable electronics and IoT device contacts

Related Products

Looking for other electronic components and hardware? Check out our 10pcs 2-Pin Spring Wire Connectors – Quick Splice Lock Terminals and our 12pcs 16mm Momentary Push Button Switch 1NO Metal 2-Pin Self-Reset for your electronics toolkit.
