GCR15 Steel Cylindrical Locating Pin 3mm – 18 Lengths Available

GCR15 Bearing Steel Cylindrical Locating Pins – High Precision, High Hardness

Engineered for demanding industrial and mechanical applications, these GCR15 bearing steel cylindrical locating pins deliver exceptional dimensional accuracy, outstanding hardness, and superior wear resistance. Whether you're building jigs and fixtures, assembling precision machinery, or working on tooling projects, these round pins provide the reliable fit and alignment you need.

Key Specifications

• Material: GCR15 Bearing Steel (high-carbon chromium steel)
• Hardness: HRC 58–63°
• Process: Quenching heat treatment for maximum durability
• Surface Roughness: Ra 0.4 – ultra-smooth finish for precision fit
• Diameter: 3mm
• Available Lengths: 3, 4, 5, 6, 7, 8, 9, 10, 12, 14, 15, 16, 18, 20, 25, 26, 28, 30mm
• Diameter Tolerance: +0 / −0.01mm
• Length Tolerance: +0 / −0.3mm
• Torque Capacity: 300
• Country of Origin: Made in Mainland China

Why Choose GCR15 Steel Locating Pins?

• ✅ High hardness (HRC 58–63°) ensures long service life even under repeated loading
• ✅ Quenching heat treatment maximizes structural integrity and wear resistance
• ✅ Ra 0.4 surface finish guarantees smooth, precise mating in bores and housings
• ✅ Tight diameter tolerance (+0/−0.01mm) ensures accurate, repeatable positioning
• ✅ 18 length options from a single 3mm diameter for versatile application coverage

Common Applications

• Jig and fixture alignment
• Precision machinery assembly
• Mold and die positioning
• Tooling and workholding setups
• Mechanical linkage and pivot points
• DIY projects requiring accurate pin alignment
