LXW5-11G2 Micro Limit Switch Short Roller Lever 1NO 1NC SPDT

LXW5-11G2 Short Hinge Roller Lever Micro Limit Switch – 1NO 1NC SPDT

The LXW5-11G2 Micro Limit Switch is a compact, reliable momentary-action switch featuring a short roller hinge lever actuator. Designed for precision position sensing and mechanical control applications, this CCC-certified switch delivers dependable SPDT (Single Pole Double Throw) switching with a 1NO/1NC contact configuration. Ideal for industrial automation, conveyor systems, machine tool controls, and DIY electrical projects.

Key Specifications

• Model Number: LXW5-11G2
• Actuator Type: Short Roller Hinge Lever
• Actuator Action: Momentary
• Contact Configuration: 1NO, 1NC (SPDT)
• Terminals: 3 Screw Terminals
• Rated Voltage: AC 380V / DC 220V
• Rated Current: 3A | AC: 100VA | DC: 10W
• Roller Diameter: 10 mm / 0.39"
• Fixing Hole Diameter: 0.4 cm / 0.16"
• Hole Center Distance: 2.7 cm / 1.1"
• Switch Body Size: 5 × 3 × 1.8 cm / 2 × 1.2 × 0.7" (L × W × H)
• Lever Length: 3.5 cm / 1.4"
• Body Color: Black
• Material: Plastic
• Certification: CCC
• Service Life: 10,000 operations

Why Choose This Micro Limit Switch?

• ✅ Versatile SPDT Configuration – Supports both normally open (NO) and normally closed (NC) circuits in a single compact unit
• ✅ High Voltage Compatibility – Rated for AC 380V and DC 220V, suitable for a wide range of industrial and hobby applications
• ✅ Momentary Action – Automatically returns to its default position when actuating force is removed, ensuring precise control
• ✅ Easy Installation – 3 screw terminals and standard fixing hole spacing make mounting and wiring straightforward
• ✅ Compact & Durable – Small form factor fits tight spaces; robust plastic housing built to handle repeated mechanical cycling
• ✅ CCC Certified – Meets Chinese Compulsory Certification standards for quality and safety assurance

Package Contents

• 1 × LXW5-11G2 Limit Switch

Made in Mainland China.

Related Products You May Like

• 12pcs 16mm Momentary Push Button Switch 1NO Metal 2-Pin Self-Reset
• 10pcs 2-Pin Spring Wire Connectors – Quick Splice Lock Terminals
• 10PCS Stainless Steel Self-Tapping Screws M2.2–M4.8 Phillips

Learn more: OSHA guidance on hand and power tools

Frequently Asked Questions

Q: What does the 1NO 1NC SPDT configuration mean on the LXW5-11G2 limit switch?

A: SPDT stands for Single Pole Double Throw. The LXW5-11G2 has one Common (COM) terminal, one Normally Open (NO) terminal, and one Normally Closed (NC) terminal. When the roller lever is not actuated, the circuit is closed between COM and NC. When the lever is pressed, the circuit switches to COM and NO — making it suitable for both "make" and "break" circuit designs in a single switch.

Q: Is the LXW5-11G2 suitable for both AC and DC applications?

A: Yes. This micro limit switch is rated for AC 380V (up to 3A, 100VA) and DC 220V (up to 10W), making it compatible with a broad range of electrical systems including industrial machinery, conveyor belt controls, automated equipment, and hobbyist electronic projects.

Q: How do I install the LXW5-11G2 micro limit switch?

A: Installation is straightforward. The switch body features standard fixing holes (0.4 cm diameter, 2.7 cm center-to-center spacing) for secure panel or bracket mounting. Connect your wires to the three screw terminals (COM, NO, NC) according to your circuit requirements. Always ensure power is off before wiring.
