OV3660 USB Camera Module 3MP Plug & Play OTG Support

OV3660 USB Camera Module – 3MP, Plug & Play, OTG Ready

Take your imaging projects to the next level with the OV3660 USB Camera Module. Featuring a high-performance OV3660 photosensitive sensor and a wide 110° field of view, this compact module delivers crisp, clear imagery straight out of the box — no drivers needed. Whether you're building a face recognition system, embedding a camera into a notebook, or setting up a QR code scanner, this versatile module has you covered.

Made in Mainland China.

Key Features

• 3MP Clarity: OV3660 sensor (1/5") delivers sharp, detailed images at up to 2048×1536 resolution.
• Wide 110° Field of View: 2.1mm focal length provides a broad visual range for expansive coverage.
• Plug & Play / Driver-Free: USB 2.0 interface requires no additional software — simply connect and start capturing.
• OTG Support: Compatible with mobile phones and tablets via USB OTG — no extra adapters required.
• Multiple Resolutions & Formats: Supports MJPG and YUY2 formats across a range of resolutions and frame rates.
• Interchangeable Lens: Modular lens design allows for easy swapping and customisation.
• Broad OS Compatibility: Works with Windows XP/7/8/10, Mac OSX, Linux, and Android.
• Wide Operating Temperature: Reliable performance from -20°C to 70°C.

Technical Specifications

What's in the Box

• 1 × OV3660 Camera Module

Applications

This camera module is ideal for a wide variety of projects and products, including:

• Notebook and all-in-one PC built-in cameras
• Face recognition systems
• External USB computer cameras
• High-speed imaging setups
• Macro and QR code scanning equipment
• DIY electronics and maker projects

You May Also Like

• 10pcs 2-Pin Spring Wire Connectors – Quick Splice Lock Terminals
• 12pcs 16mm Momentary Push Button Switch 1NO Metal 2-Pin Self-Reset
• 10PCS Stainless Steel Self-Tapping Screws M2.2–M4.8 Phillips

Note: Actual colour may vary slightly due to different monitor settings and lighting conditions. Please allow ±1–2cm measuring deviation due to manual measurement.

Learn more: EPA guidance on lithium-ion battery handling

Frequently Asked Questions

Q: Does the OV3660 USB camera module require any drivers or software to install?

A: No — the OV3660 USB camera module is completely driver-free. Simply plug it into your USB 2.0 port and it will be recognised automatically on Windows XP/7/8/10, Mac OSX, Linux, and Android devices.

Q: Can I use the OV3660 camera module with my smartphone via OTG?

A: Yes! The OV3660 module supports USB OTG, allowing you to connect it directly to a compatible smartphone or tablet for mobile imaging applications.

Q: What resolution and frame rate does the OV3660 module support?

A: It supports multiple resolutions: up to 2048×1536 at 15fps in MJPG format, 1280×1080 at 30fps, and 640×480 at 30fps, as well as YUY2 format options at various frame rates to suit your specific project requirements.

Q: Is the lens on the OV3660 camera module interchangeable?

A: Yes, the lens is interchangeable, giving you the flexibility to swap lenses for different focal lengths or fields of view to meet your specific application needs.
