TC1-1T RF Balun Transformer 0.4–500MHz 1:1 50Ω Flux Coupled

TC1-1T RF Balun Transformer — 0.4–500MHz, 1:1 Impedance, 50Ω

Upgrade your RF circuit builds with the TC1-1T RF Balun Transformer — a compact, high-quality flux-coupled balanced-to-unbalanced converter designed to deliver reliable signal conversion across an impressively wide frequency range. Whether you're prototyping, repairing, or building RF equipment, this miniature transformer is a go-to component for engineers and hobbyists alike.

Key Specifications

• Impedance Ratio: 1:1 CT (Center-Tapped)
• Characteristic Impedance: 50Ω
• Frequency Range: 0.4 MHz to 500 MHz
• RF Power: 0.50W
• DC Current: 30mA
• Operating Temperature: -40°C to +85°C
• Dimensions: 5 × 4 × 3 mm
• Package Quantity: 2 or 5 pieces

Why Choose the TC1-1T RF Balun?

• ✅ Wideband Performance: Covers 0.4 to 500 MHz — suitable for HF, VHF, and UHF applications
• ✅ Flux-Coupled Design: Ensures efficient signal transfer with minimal loss between balanced and unbalanced circuits
• ✅ Ultra-Compact Form Factor: At just 5×4×3mm, it fits easily into tight PCB layouts
• ✅ Wide Temperature Tolerance: Operates reliably from -40°C to +85°C, making it suitable for demanding environments
• ✅ No Battery Required: Purely passive component — no power supply needed
• ✅ Multi-Pack Value: Available in 2-piece or 5-piece packs for your project needs

Ideal Applications

The TC1-1T is widely used in RF circuit design, antenna matching networks, signal converters, software-defined radio (SDR) setups, test equipment, and communication systems requiring balanced-to-unbalanced signal transformation at 50Ω impedance.

Made in Mainland China.
