XYZ Manual Linear Slide Table Digital Display & Handwheel S100

XYZ Manual Linear Slide Table – T-Type Cross Precision Guide Rail with Digital Display

Achieve exceptional positioning accuracy with this XYZ Manual Linear Slide Table (Model S100). Engineered for laboratory, optical, machining, and inspection applications, this three-axis cross slide module features a T-type lead screw mechanism paired with a digital display readout and a smooth handwheel for effortless, micrometer-level fine adjustment. Whether you're aligning optical components, calibrating instruments, or running precision machining operations, this guide rail module delivers consistent, repeatable results.

Key Features

• Three-Axis (XYZ) Control: Independent X, Y, and Z axes allow comprehensive spatial positioning with a single compact unit.
• Digital Display Readout: Built-in digital indicator provides real-time, accurate position readings for precise, repeatable adjustments.
• T-Type Lead Screw Drive: High-quality T-type screw mechanism ensures smooth, backlash-minimized linear travel with fine-thread resolution.
• Ergonomic Handwheel: Large, easy-grip handwheel allows controlled manual actuation for micro-level positioning without slipping.
• Heavy-Duty Construction: Rigid platform and precision-ground guide rails provide stable, vibration-resistant performance even under load.
• Versatile Mounting: Compatible with optical tables, machine beds, and custom fixtures; multiple mounting hole patterns included.
• Compact Cross Slide Design: Stacked axis configuration minimizes overall footprint while maximizing range of motion.

Ideal Applications

• Optical alignment and laser positioning
• Microscopy and sample stage adjustment
• CNC and machining setups
• Quality control and coordinate measurement
• Laboratory research and instrumentation

Specifications
